Single Drawer

This drawer is easy to install. Built for strength and longevity, it features a 1.5mm powder-coated galvanized steel frame and drawers with a 100kg load rating. Made from galvanised steel with Nardo Grey powder coat covering all sides for extra corrosion resistance. Comes standard with anti-rollback locking mechanism keeps drawers secure even on inclines.

• 1.5mm powder coated galvanised steel frame and 1.2mm powder coated galvanised steel drawer.
• Nardo Grey powder coat covers all sides of the galvanised sheet to prevent corrosion and increase durability.
• Marine carpeted plywood top
• 100kg load rating per drawer
• Anti rollback locking mechanism means the drawers will stay open even if the vehicle is parked on a slope
• Choose the Sliding Drawer Top Option to add a functional slide which can be used to help load heavy tools, machinery, loads or as a fridge slide


Do you own a van?

Organise the back of your cargo space by adding some drawers. We have size variants to suit almost all van fitouts. Simply decide whether you want your drawers to open out through the rear door or the side door and measure the space that you'd like the drawers to fit in. Many customers would opt for our wider drawers to fill up the space available when the side door is open or a pair of drawers to fill up the space available when the rear door is open. Any drawers of the same height can be bolted together.

• Being powder coated, not only do they look the part, they offer greater protection against damage from moving/rolling cargo that's thrown into the back of the van
• The drawer is the solid foundation to an organised cargo space, the plywood top means you are able to easily modify it to suit your needs. You may mount a small shelf on top or attach a Milwaukee Packout Bracket or similar so you can easily load and unload your tool chests without them sliding around your van.

How do I install it?

Complicated wing kits and brackets are not required if you're only looking to fill up a rectangular void with our drawers*. Simply bolt the drawers together (if applicable), find 4 points to drill through your van floor and secure the drawers down.

To find 4 suitable drilling points, have a friend crawl under the van while you tap on the metal floor where you think a suitable drilling spot would be. Your friend should be able to feel the vibrations to see where the hole would be on the bottom. They can give feedback on whether that spot would be free of obstructions such as chassis rails, exhaust heatshields or wiring harnesses. Alternatively, you can measure of reference points such as tie down points which are visible from underneath the van or simply the edge of the van.

*Fully covered van drawer systems are available for select vehicles such as Toyota Hiace.
